Flexible 20AWG TPE Insulated TPE Jacketed Electrical Cable 2 Core

100m
MOQ
Negotiation
Price
Flexible 20AWG TPE Insulated TPE Jacketed Electrical Cable 2 Core
Features Gallery Product Description Request A Quote
Features
Specifications
Features: Flexible
Insulation: TPE Insulated
Working Temperature: -40℃~+90℃
Sheath: TPE Jacket
Core Number: 2 Core Or Multi Core
Conductor: Stranded Bare Copper Wire
Rated Voltage: 600/1000V
Drain Wire: Tinned Copper Wire
Customized Service: Yes
Customized Product: Available As Per Technical Datesheet
High Light:

TPE Jacketed Electrical Cable

,

20AWG TPE Insulated Electrical Cable

,

2 Core TPE Insulated Wire

Basic Infomation
Place of Origin: China
Brand Name: SANCO
Certification: ISO9001
Model Number: TPE cable
Payment & Shipping Terms
Packaging Details: Cable tray or Packing in roll with carton box
Delivery Time: 5-10days
Supply Ability: 100000M/Per Month
Product Description

Flexible 2 Core 20AWG TPE Insulated TPE Jacketed Electrical Cable



About TEP Electrical Cable

TPE is commonly used for flexible cables, as it can reliably withstand mechanical loads and has resistance to external influences such as chemicals and extreme temperatures,TPE material has high elasticity and rebound shrinkage similar to rubber and also with good weather resistance and temperature resistance, better than the plastic materials also has good electrical insulation performance, excellent chemical resistance and uv resistance


Application:

This cable is used for indoor and outdoor applications,for elevated warehouse storage and extraction equipment, processing equipment,machine tools, fast conveying system, clean room, semiconductor insertion technology, quay crane, outdoor crane, low temperature applications, especially for horizontal overhead and long travel up to 400 meters or more.


Structure of TEP Electrical Cable

1. Conductor:bare copper wire

2. Insulation: TPE insulation

3. Wire core: twisted

4. Jacket: special TPE Jacket



Properties of TEP Electrical Cable

1. Rated Voltage:600/1000V

2. Insulation resistance:>20MOhmxcm

3. Insulation:Minimum bending radius mobile installation:7.5 x cable diameter,Fixed installation:4 x cable diameter

4. Operating temperature: -35℃~+90℃(mobile installation,-40℃~+90℃( Fixed installation)

Flexible 20AWG TPE Insulated TPE Jacketed Electrical Cable 2 Core 0



Specification
(mm2)
Reference cable OD
(mm)
Estimate conductor weight
(kg/km)
Estimate cable weight
(kg/km)
4G1.5 8.5 55 105
4G2.5 10 91 156
4G4.0 12 152 234
4G6.0 14 235 341
5G6.0 15 283 414
4G10.0 17 391 531
5G10.0 18.5 489 655
4G16 19.5 610 788
5G16 23 763 1072
4G25 24.5 944 1245
4X6 14 235 341
4X10 17 391 531
4X16 19.5 610 788
3X50 30 1423 1947

 Noted:Specification and core no. are not limited to above regulation,they could be customized.
