PTFE FEP PFA high temperature Coated 12 Gauge High Temp Wire Two Core Tinned

PTFE FEP PFA high temperature Coated 12 Gauge High Temp Wire Two Core Tinned
Features Gallery Product Description Request A Quote
Features: High Temperature Resistant
Insulation: Ptfe Fep Pfa High Temperature Insulated
Max. Working Temperature: -65℃~+150℃
Conductor: Tinned Copper Wire
Wire Gauge: 32awg To 10awg Gauge
Core Number: Single Core Or Two Core
Rated Voltage: AC 600V
Shelf Life: One Year
Service: OEM ODM Accept
Customized Product: Available As Per Technical Data
High Light:

FEP 12 gauge high temp wire


PTFE12 gauge high temp wire


PFA high temperature coated copper wire

Basic Infomation
Place of Origin: China
Brand Name: SANCO
Certification: ISO9001
Model Number: AFR-250,AF-200,AFK-250
Payment & Shipping Terms
Packaging Details: Cable tray or Packing in roll with carton box
Delivery Time: 3~8days
Supply Ability: 250000M/Per Month
Product Description

Ptfe Fep Pfa high temperature Insulated Two Core Tinned Copper Wire Supplier


You can install high temperature high temperature wires in harsh environments and extreme temperatures,You have to make sure that you choose the right cables and wires for specific conditions. It’s essential to make sure the wire’s lifespan is not compromised, Using cable and wire products not in their recommended temperature range will result in failure or even accidents.


high temperature PTFE: PTFE wire can be continuously used at 250 degree, very low coefficient of friction, good wear resistance and excellent chemical stability.
high temperature FEP: FEP wire with excellent chemical stability, excellent non-stick characteristics, the maximum operating temperature is 200℃.
high temperature PFA: PFA wire has higher continuous service temperature of 250℃, stronger toughness, especially suitable for use in high temperature anti-stick and chemical resistance applications
high temperature ETFE: ETFE wire is a copolymer of ethylene and tetrafluoroethylene with excellent chemical resistance and continuous operation at 150℃


Sanco cable can provide standard off-the-shelf high temperature wire or cable as well as design a product that will suit any high temperature environment or application. Common high temperature applications include:

1. Aviation Wiring
2. Aerospace Wiring
3. Electronics Wiring
4. Medical Wiring
5. Appliance Wiring
6. Lighting Industry
7. Military Applications
8. Oil and Gas Industry Applications
9. Chemical Industry Applications



Wire gauge Section area
Conductor construction
Insulation thickness
Reference OD
Max. Conductor resistance at 20
28awg 0.08mm2 7/0.12 0.15 0.66 239
26awg 0.14mm2 7/0.16 0.15 0.78 239
24awg 0.2mm2 7/0.2 0.15 0.9 150
22awg 0.4/0.3mm2 19/0.16 0.15 1.1 94.2
20awg 0.6/0.5mm2 19/0.2 0.15 1.3 32.4
18awg 1mm2 19/0.26 0.2 1.7 20.4
16awg 1.2mm2 19/0.28 0.2 1.8 16.6
14awg 2mm2 19/0.36 0.33 2.46 10
12awg 3mm2 37/0.32 0.33 2.9 6.63
10awg 5mm2 37/0.4 0.33 3.46 4.13

PTFE FEP PFA high temperature Coated 12 Gauge High Temp Wire Two Core Tinned 0PTFE FEP PFA high temperature Coated 12 Gauge High Temp Wire Two Core Tinned 1
