Blue Color PTFE Silver Plated Stranded Copper Wire 16 Gauge

100m
MOQ
Negotiation
Price
Blue Color PTFE Silver Plated Stranded Copper Wire 16 Gauge
Features Gallery Product Description Request A Quote
Features
Specifications
Features: High Temp Resistant
Application: Electrical Connection
Insulation: PTFE Insulated
Condouctor: Silver Plated
Max. Temperature: -60~+250℃
Wire Gauge: 16awg
Color: 9 Colors
Rated Voltage: 125V, 300V, 600V
Shelf Life: 1 Year
Service: OEM ODM Accept
Customized Wire: Available As Per Detailed Technical Data
High Light:

16 gauge PTFE stranded copper wire

,

PTFE silver plated stranded copper wire

,

PTFE 16 gauge copper wire

Basic Infomation
Place of Origin: China
Brand Name: SANCO
Certification: ISO9001
Model Number: AFR-250
Payment & Shipping Terms
Packaging Details: Cable tray / Packing in roll with carton box
Delivery Time: 3~8days
Payment Terms: T/T, L/C
Supply Ability: 250000M/Per Month
Product Description

Ptfe Silver Plated Stranded Copper Wire,16awg high temperature Copper Wire​



It has excellent corrosion resistance, oil resistance, strong acid, strong alkali resistance, strong oxidant, etc. Excellent electrical insulation performance, high voltage resistance, low loss at high frequency, no moisture absorption, large insulation resistance; It has excellent fire resistance, aging resistance and long service life.



Application:

1. For connecting internal electrical equipment of various kinds of aircraft, airships, armored vehicles, ships under high temperature environment.
2. In industrial and mining enterprises such as metallurgy, petroleum, chemical and power plants, and is used as a connecting line for various electrical appliances, instruments and automatic devices under high temperature conditions and harsh environments



Property:

1. The conductor is made of 0.03-0.08mm copper wire or silver-plated copper wire wrapped by ptfe film
2. Core can be made: 1, 7, 19, 30, 42, 49, 75, 100
3. Color: black, brown, red, orange, yellow, green, blue, purple, gray, white
4. Long-term working temperature: copper core -60 ~ +200℃, silver-plated copper core -60 ~ +250℃



Blue Color PTFE Silver Plated Stranded Copper Wire 16 Gauge 0



Conductor
Insulation thickness
mm
Wire outer diameter
mm
Resistance of insualtion
Nominal section area
mm2
single wire x dia. Conductor Dia.
mm
110V 250V 600V AFR-250 type AFRP-250 type MΩ·km
mm 110V 250V 600V 110V 250V 600V
0.013 7×0.05 0.15 0.1 0.15 0.25 0.38 0.49 0.71 0.7 0.82 1.02 5×103
0.035 7×0.08 0.24 0.1 0.15 0.25 0.47 0.58 0.81 0.85 0.91 1.14
0.06 7×0.10 0.3 0.1 0.15 0.25 0.55 0.65 0.87 0.9 0.97 1.2
0.08 7×0.12 0.36 0.1 0.15 0.25 0.6 0.7 0.93 1 1.03 1.26
19×0.07
0.1 7×0.14 0.42 0.1 0.15 0.25 0.7 0.83 1 1.05 1.15 1.3
19×0.08
0.14 7×0.16 0.5 0.1 0.15 0.25 0.73 0.85 1.05 1.05 1.18 1.45
19×0.10
0.2 7×0.20 0.6   0.15 0.3 0.85 0.97 1.3 1.3 1.4 1.7
19×0.12
0.35 7×0.25 0.8   0.15 0.3   1.2 1.5   1.6 1.9
19×0.16
0.5 7×0.30 0.9   0.15 0.3   1.3 1.6   1.7 2
19×0.18
0.8 7×0.37 1.1   0.2 0.3   1.65 1.85   2.05 2.3
19×0.23
1 19×0.26 1.3   0.2 0.3   1.88 2   2.25 2.45
1.2 19×0.28 1.4   0.2 0.3   1.95 2.15   2.38 2.55
1.5 19×0.32 1.6   0.2 0.3   2.15 2.35   2.63 2.83
2 19×0.37 1.85   0.2 0.3   2.4 2.6   2.97 3.08
2.5 19×0.14 2.34   0.2 0.35     2.95   3.2 3.43
49×0.26
3 49×0.28 2.52   0.2 0.35     3.1   3.37 3.5
4 49×0.32 2.88     0.35     3.52     4.12
6 49×0.39 3.51     0.35     4.15     4.75

Noted:Specification and core no. are not limited to above regulation,they could be customized.

Blue Color PTFE Silver Plated Stranded Copper Wire 16 Gauge 1

Blue Color PTFE Silver Plated Stranded Copper Wire 16 Gauge 2
