42 Strands 0.08mm Chemical Resistant PTFE Insulated Silver Plated Copper Wire for High Temperature Applications

100
MOQ
42 Strands 0.08mm Chemical Resistant PTFE Insulated Silver Plated Copper Wire for High Temperature Applications
Features Gallery Product Description Request A Quote
Features
Specifications
Conductor Material: Bare Copper
Insulation Material: PTFE Insulated
Rated Voltage: AC 220V
Conductor Type: Stranded
Wire Gauge: 24awg
Strand Count: 42 Strands
Strand Diameter: 0.08mm
Working Temperature: -60℃ To +250℃
Color Options: 11 Colors
Shielding Material: Tinned Copper Wire
Core Number: Single Core
Packing Length: 305m/roll
Temperature Resistance: 250 Degree Resistance
Conductor Plating: Silver Plated
Wire Flexibility: Good Flexibility
Highlight:

42 Strands PTFE Insulated Wire

,

0.08mm Silver Plated Copper Wire

,

Chemical Resistant Polytetrafluoroethylene Wire
Basic Infomation
Place of Origin: Hunan, China
Brand Name: Sanco cable
Model Number: AFR-250
Payment & Shipping Terms
Product Description
24AWG 42 Strands 0.08mm Silver Plated Polytetrafluoroethylene Wire
Product Description
Polytetrafluoroethylene (PTFE) Wire is a high-performance electrical wire insulated with PTFE film, offering exceptional resistance to high temperatures, chemicals, and excellent electrical insulation properties.
Key Features:
  • Ideal for high-temperature and chemically aggressive environments
  • PTFE film covering provides superior protection against harsh conditions
  • Widely used in aerospace, automotive, and industrial applications
  • Delivers high performance and reliability in demanding situations
42 Strands 0.08mm Chemical Resistant PTFE Insulated Silver Plated Copper Wire for High Temperature Applications 0
Specifications
Application Internal wiring for electronic equipment, electrical appliances, and instruments
Advantages Small outer diameter, light weight, excellent flexibility, easy to weld, high temperature resistant, anti-aging, anti-interference
Available Colors Black, brown, red, orange, yellow, green, blue, purple, gray, white, and transparent
42 Strands 0.08mm Chemical Resistant PTFE Insulated Silver Plated Copper Wire for High Temperature Applications 1
Conductor Silver plated copper wire
Insulation PTFE insulated
Conductor Type Stranded
Working Temperature -60℃ to +250℃
Rated Voltage AC 220V
Wire Gauge 36AWG to 3/0AWG
Core Number Single Core
Packing Length 305m/roll
Free Sample Yes
42 Strands 0.08mm Chemical Resistant PTFE Insulated Silver Plated Copper Wire for High Temperature Applications 2
Company Profile
Shenzhou Special Cable is a leading manufacturer of custom wires and cables, specializing in high temperature wires (PTFE, PFA, FEP, ETFE), robot cables, crane cables, and drag chain cables for aerospace, robotics, oil fields, wind power, and electronics industries.
Company Highlights:
  • 20+ years of specialized cable manufacturing experience
  • Supplied products for National Rocket and China Manned Space Engineering Program
  • Certified by weapons and equipment quality management system, ISO9001, and CCC
  • 7000+ sqm standard factory with 14 production lines
  • 1500+ sqm professional testing laboratory with advanced equipment
42 Strands 0.08mm Chemical Resistant PTFE Insulated Silver Plated Copper Wire for High Temperature Applications 3
Quality Assurance
All products undergo strict inspection before shipment, including annealing test, tensile test, conductor resistance test, insulation thickness test, and overall diameter measurement.
42 Strands 0.08mm Chemical Resistant PTFE Insulated Silver Plated Copper Wire for High Temperature Applications 4
Why Choose Us
  • 20+ years of special cable R&D and manufacturing expertise
  • Certified supplier for China's aerospace and military applications
  • Advanced testing equipment and professional QC team
  • Low MOQ for custom cables
  • Free samples and design services available
  • 1-3 year warranty period
42 Strands 0.08mm Chemical Resistant PTFE Insulated Silver Plated Copper Wire for High Temperature Applications 5
Packing & Delivery
We provide professional, environmentally friendly packaging options including carton boxes, spools, barrels, pallets, and wooden trays to ensure safe transportation.
42 Strands 0.08mm Chemical Resistant PTFE Insulated Silver Plated Copper Wire for High Temperature Applications 6
