Fine Stranded PFA Insulated Wire with 600V Rated Voltage for Industrial Heating Applications in 1-5 Core and 0.05-6mm2 Size

500
MOQ
Fine Stranded PFA Insulated Wire with 600V Rated Voltage for Industrial Heating Applications in 1-5 Core and 0.05-6mm2 Size
Features Gallery Product Description Request A Quote
Features
Specifications
Conductor Material: Copper, Silver Plated Copper, Tinned Plated Copper
Diameter: 20 AWG, 22 AWG, 24 AWG, 18 AWG
Insulation Material: PFA
Rated Voltage: AC600V And Below
Conductor Type: Stranded, Solid Or Stranded
Shape: Round
Single Wire Size: 1.0 Mm, 0.5 Mm, 0.3 Mm, 0.2 Mm
Temperature Range: -65℃~+250℃
Core Number: 1-5 Core
Sectional Area: 0.05-6mm2
Insulation Thickness: 0.20mm, 0.30mm, 0.35mm, 0.40mm, 0.50mm, 0.60mm, 0.70mm, 0.80mm, 1.0mm, 1.2mm
Outer Diameter: 0.70mm, 1.20mm, 1.40mm, 1.60mm, 1.85mm, 2.00mm, 2.10mm, 2.40mm, 2.65mm, 3.05mm, 3.60mm, 4.20mm, 5.20mm, 5.80mm, 7.0mm, 8.0mm, 8.8mm, 10.4mm, 12.2mm, 14.6mm, 17.2mm
Max Conductor Resistance: 376.2 Ω/km, 83.5 Ω/km, 49.5 Ω/km, 36.0 Ω/km, 22.7 Ω/km, 19.0 Ω/km, 15.3 Ω/km, 11.7 Ω/km, 9.45 Ω/km, 6.86 Ω/km, 4.51 Ω/km, 3.05 Ω/km, 2.16 Ω/km, 1.68 Ω/km, 1.13 Ω/km, 0.886 Ω/km, 0.734 Ω/km, 0.511 Ω/km, 0.358 Ω/km, 0.270 Ω/km, 0.210 Ω/km
Insulation Resistance: ≥1x10³ MΩ
Test Voltage: 2000V/5min (AC 50Hz)
Highlight:

600V Rated Voltage PFA Insulated Wire

,

1-5 Core PFA Coated Wire

,

0.05-6mm2 Size High Temperature Wire
Basic Infomation
Place of Origin: Hunan, China
Brand Name: Sanco Cable
Model Number: AFK-250
Payment & Shipping Terms
Product Description
Fine Stranded PFA Insulated Wire for Industrial Heating Applications
PFA insulated wire features polytetrafluoroethylene (PFA) insulation, a thermoplastic polymer offering exceptional resistance to heat, chemicals, and moisture. Ideal for high-temperature environments, corrosive chemical applications, and medical devices, this wire is widely used in aerospace, automotive, electronics, and telecommunications industries where reliable performance in harsh conditions is critical.
Key Features
  • Designed for aviation and electronics industries under high-temperature radiation as instrumentation connectors
  • Small diameter with excellent abrasion and scratch resistance
  • Easy to peel with superior temperature resistance (-65℃ to +250℃)
  • Anti-aging, corrosion resistant, and anti-interference properties
Technical Specifications
Working Conditions:
- Temperature range: -65℃ to +250℃
- Rated voltage: AC110V, AC250V, AC600V or lower
- Insulation resistance: ≥1×10³MΩ
- Relative humidity: 95%±3
- Test voltage: 2000V/5min (AC 50Hz)
Product Types
Type Description
AFK-250 Silver plated copper wire core high temperature PFA insulated electric wire
AFKP-250 Silver plated copper wire high temperature PFA insulated shielding electric wire
Cable Construction
Insulation: PFA
Conductor: Silver plated copper wire, Tinned copper wire, or bare copper wire
Fine Stranded PFA Insulated Wire with 600V Rated Voltage for Industrial Heating Applications in 1-5 Core and 0.05-6mm2 Size 0
Detailed Specifications
Sectional Area (mm²) Conductor Construction Insulation Thickness Outer Diameter Max Conductor Resistance DC20℃(Ω/km)
0.05 7/0.10mm 0.20mm 0.70mm 376.2
0.20 7/0.20mm 0.30mm 1.20mm 83.5
0.35 19/0.16mm 0.30mm 1.40mm 49.5
0.50 19/0.18mm 0.35mm 1.60mm 36.0
0.75 19/0.23mm 0.35mm 1.85mm 22.7
1.0 19/0.26mm 0.35mm 2.00mm 19.0
1.20 19/0.28mm 0.35mm 2.10mm 15.3
1.50 19/0.32mm 0.40mm 2.40mm 11.7
2.0 19/0.37mm 0.40mm 2.65mm 9.45
2.5 19/0.41mm 0.50mm 3.05mm 6.86
4.0 37/0.37mm 0.50mm 3.60mm 4.51
6.0 37/0.45mm 0.50mm 4.20mm 3.05
8.0 133/0.28mm 0.50mm 5.20mm 2.16
10 133/0.62mm 0.50mm 5.80mm 1.68
16 133/0.39mm 0.60mm 7.0mm 1.13
20 133/0.45mm 0.60mm 8.0mm 0.886
25 196/0.40mm 0.60mm 8.8mm 0.734
35 494/0.30mm 0.70mm 10.4mm 0.511
50 396/0.40mm 0.80mm 12.2mm 0.358
70 551/0.40mm 1.0mm 14.6mm 0.270
95 760/0.40mm 1.2mm 17.2mm 0.210
Fine Stranded PFA Insulated Wire with 600V Rated Voltage for Industrial Heating Applications in 1-5 Core and 0.05-6mm2 Size 1
Product Variants
Feature Options
Conductor Materials Silver Plated Copper or Tinned Plated Copper
Conductor Type Solid or Stranded
Number of Cores Single Core, 2 Cores, 3 Cores, 4 Cores, 5 Cores
Insulation PFA, FEP, PTFE, ETFE Insulated
Rated Voltage 600V or Below
Color White, Black, Brown, Green, Red, Yellow, Blue, etc.
Working Temperature -65℃ to +250℃
About Xiangtan Shenzhou Special Cable Co., LTD
As a stable wire and cable supplier for China's aerospace and military sectors with 21 years of experience, we produce our own cable compounds to maintain superior quality and competitive pricing. Our product range includes high temperature wires, PTFE cables, FEP cables, PFA wires, ETFE cables, robot cables, drag chain cables, super flexible cables, hook up wires, electronic cables, and power cables.
With advanced production facilities and an integrated management system, we collaborate with universities and research institutes to develop customized cable solutions. Our commitment to quality includes a comprehensive warranty program covering repair, replacement, and return for any manufacturing defects.
Fine Stranded PFA Insulated Wire with 600V Rated Voltage for Industrial Heating Applications in 1-5 Core and 0.05-6mm2 Size 2
Our Honors
  • Contributed to China's manned space flight projects including Shenzhou 7
  • Participated in the "Arrow of God" project for outer space exploration
  • Recognized by China Academy of Launch Vehicle Technology
Contact Us
For more information about our Fine Stranded PFA Insulated Wire or other products, please visit our website or contact our sales team.
Fine Stranded PFA Insulated Wire with 600V Rated Voltage for Industrial Heating Applications in 1-5 Core and 0.05-6mm2 Size 3
