High Temperature Silver Plated Copper PFA Insulated Wire with Multiple AWG Sizes AC600V Rated and 1-5 Core Options

500
MOQ
High Temperature Silver Plated Copper PFA Insulated Wire with Multiple AWG Sizes AC600V Rated and 1-5 Core Options
Features Gallery Product Description Request A Quote
Features
Specifications
Conductor Material: Silver Plated Copper Or Tinned Plated Copper
Diameter: 20 AWG, 22 AWG, 24 AWG, 18 AWG
Insulation Material: PFA
Rated Voltage: AC600V And Below
Conductor Type: Stranded, Solid Or Stranded
Single Wire Size: 1.0 Mm, 0.5 Mm, 0.3 Mm, 0.2 Mm
Temperature Range: -65℃~+250℃
Core Number: 1-5 Core
Sectional Area: 0.05-6mm2
Insulation Thickness: 0.20mm To 1.2mm
Outer Diameter: 0.70mm To 17.2mm
Max Conductor Resistance: 376.2 Ω/km To 0.210 Ω/km
Insulation Resistance: Not Less Than 1x103MΩ
Relative Humidity: 95%±3
Test Voltage: 2000V/5min (AC 50Hz)
Highlight:

Multiple AWG Sizes PFA Insulated Wire

,

AC600V Rated Silver Plated Copper Wire

,

1-5 Core High Temperature Wire
Basic Infomation
Place of Origin: Hunan, China
Brand Name: Sanco Cable
Model Number: AFK-250
Payment & Shipping Terms
Product Description
High Temp Silver Plated Copper Fluoropolymer Wire
Product Description

PFA insulated wire is a type of electrical wire featuring polytetrafluoroethylene (PFA) insulation. This thermoplastic polymer offers exceptional resistance to heat, chemicals, and moisture, making it ideal for demanding applications in aerospace, automotive, electronics, and telecommunications industries where reliable performance in harsh conditions is essential.

Key Features
  • Designed for aviation and electronics industries under high temperature radiation conditions
  • Small diameter with excellent abrasion and scratch resistance
  • Easy to peel with superior temperature resistance (-65℃ to +250℃)
  • Anti-aging, corrosion resistant, and anti-interference properties
Technical Specifications
Parameter Value
Working temperature -65℃ to +250℃
Rated voltage AC110V, AC250V, AC600V or lower
Insulation resistance ≥1×10³MΩ
Relative humidity 95%±3
Test voltage (AC 50Hz) 2000V/5min
Product Types
Type Description
AFK-250 Silver plated copper wire core high temperature PFA insulated electric wire
AFKP-250 Silver plated copper wire high temperature PFA insulated shielding electric wire
Cable Construction

Insulation: PFA
Conductor: Silver plated copper wire, Tinned copper wire, or bare copper wire

High Temperature Silver Plated Copper PFA Insulated Wire with Multiple AWG Sizes AC600V Rated and 1-5 Core Options 0
Detailed Specifications
Sectional Area (mm²) Conductor Construction (mm) Insulation Thickness (mm) Outer Diameter (mm) Max Conductor Resistance DC20℃ (Ω/km)
0.05 7/0.10 0.20 0.70 376.2
0.20 7/0.20 0.30 1.20 83.5
0.35 19/0.16 0.30 1.40 49.5
0.50 19/0.18 0.35 1.60 36.0
0.75 19/0.23 0.35 1.85 22.7
1.0 19/0.26 0.35 2.00 19.0
1.20 19/0.28 0.35 2.10 15.3
1.50 19/0.32 0.40 2.40 11.7
2.0 19/0.37 0.40 2.65 9.45
2.5 19/0.41 0.50 3.05 6.86
4.0 37/0.37 0.50 3.60 4.51
6.0 37/0.45 0.50 4.20 3.05
8.0 133/0.28 0.50 5.20 2.16
10 133/0.62 0.50 5.80 1.68
16 133/0.39 0.60 7.0 1.13
20 133/0.45 0.60 8.0 0.886
25 196/0.40 0.60 8.8 0.734
35 494/0.30 0.70 10.4 0.511
50 396/0.40 0.80 12.2 0.358
70 551/0.40 1.0 14.6 0.270
95 760/0.40 1.2 17.2 0.210
High Temperature Silver Plated Copper PFA Insulated Wire with Multiple AWG Sizes AC600V Rated and 1-5 Core Options 1
Product Variations
Feature Options
Conductor Materials Silver Plated Copper or Tinned Plated Copper
Conductor Type Solid or Stranded
Number Cores Single Core, 2 Cores, 3 Cores, 4 Cores, 5 Cores
Insulation PFA, FEP, PTFE, ETFE Insulated
Rated Voltage 600V or Below
Color White, Black, Brown, Green, Red, Yellow, Blue, etc.
Working Temperature -65℃ to +250℃
About Our Company

Xiangtan Shenzhou Special Cable Co., LTD is a stable wire and cable supplier for China's aerospace and military sectors with 21 years of experience. We produce our own cable compounds, enabling us to maintain superior quality and competitive pricing for global customers.

Our Capabilities
  • Advanced production facilities and integrated management system
  • Collaboration with universities and research institutes
  • Custom cable solutions tailored to customer requirements
  • Comprehensive quality control throughout manufacturing process
High Temperature Silver Plated Copper PFA Insulated Wire with Multiple AWG Sizes AC600V Rated and 1-5 Core Options 2
Quality Commitment

We guarantee repair, replacement, and return for products with manufacturing defects, and compensate for direct economic losses caused by quality issues.

Frequently Asked Questions
Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specializing in research, development, and sales of military and consumer cable wire and cable compounds.
Q: What is your company's strengths?
A: As a stable supplier to China's aerospace and military sectors with 21 years experience, we produce our own cable compounds to ensure superior quality and competitive pricing.
Q: How do you guarantee your product quality?
A: We implement strict quality control from design through manufacturing, including materials procurement, semi-finished product testing, and finished product inspection.
Q: What's the warranty of your products?
A: We provide 1 year complete warranty service with unconditional replacement or return for products with quality problems.
Q: How can I get the samples?
A: We can prepare sample orders. For small quantities available in stock, samples are free with customer responsible for freight costs.
