Heat Resistance 600V Rated PFA Insulated Wire with Silver Plated Stranded Conductor in 16 18 26 Gauge

100
MOQ
Heat Resistance 600V Rated PFA Insulated Wire with Silver Plated Stranded Conductor in 16 18 26 Gauge
Features Gallery Product Description Request A Quote
Features
Specifications
Conductor Material: Silver Plated
Diameter: 20 AWG
Insulation Material: PFA
Rated Voltage: 600V
Conductor Type: Stranded
Shape: Round
Single Wire Size: 0.2 Mm
Temperature Range: -60~+250℃
Conductor Resistance: 41.3Ω/km(at 20℃)
Color Options: 10 Basic Colors
Shielding Type: Braided
Wire Gauge: 36awg~3/0awg
Core Number: Single Core
Packing Length: 100m/roll Or 500m/roll
Working Temperature: -65℃ ~ +250℃
Highlight:

600V Rated PFA Insulated Wire

,

Silver Plated PFA Insulated Wire

,

Stranded Conductor PFA Cable
Basic Infomation
Place of Origin: Hunan, China
Brand Name: Sanco cable
Model Number: AFK-250
Payment & Shipping Terms
Product Description
Heat Resist PFA Silver Plated Wire 16 18 26 Gauge
Product Overview

PFA wire is a high-performance hook-up wire that uses perfluoroalkoxy (PFA) insulation material, a fluoropolymer with properties similar to PTFE but with enhanced flexibility and melt-processability.

Key Features
  • Exceptional chemical and solvent resistance
  • Withstands extreme temperatures from -200°C to +260°C (-328°F to +500°F)
  • Low friction, non-stick surface resists dirt and contaminant buildup
  • Superior electrical performance in demanding environments
  • Available in multiple gauges (16, 18, 26 AWG) with silver-plated conductors
Heat Resistance 600V Rated PFA Insulated Wire with Silver Plated Stranded Conductor in 16 18 26 Gauge 0
Specifications
Application Circuit connections for instruments and precision equipment in high temperature environments
Advantages Small diameter, wear resistant, scratch resistant, high/low temperature resistant, corrosion resistant, anti-interference
Available Colors Black, brown, red, yellow, green, blue, purple, gray, white
Conductor Silver plated copper wire or nickel plated copper wire
Insulation PFA
Conductor Type Stranded or solid
Working Temperature -65°C to +250°C
Rated Voltage AC 600V
Wire Gauge 36AWG to 3/0AWG
Core Number Single Core
Packing Length 100m/roll or 500m/roll
Free Sample Yes
Industrial Applications
Aerospace

Wire harnessing in aircraft and spacecraft

Automotive

High-temperature electrical connections

Electronics

Precision instrument wiring

Medical Equipment

Sensor wiring for chemical analysis

Manufacturer Profile

Shenzhou Special Cable is a leading manufacturer of high-performance wires and cables with over 20 years of experience in the industry. Our products are used in national aerospace programs and meet rigorous quality standards including ISO9001 and CCC certification.

Quality Assurance
  • 7000+ sqm standard factory with 14 production lines
  • 1500+ sqm professional testing laboratory
  • Advanced cable testing equipment
  • Professional QC team
  • Comprehensive pre-shipment inspections
Packaging Options
Roll with carton boxes
Spool with carton boxes
Barrel or pallet
Wooden tray
Contact Us

For inquiries about our PFA Silver Plated Wire or other specialty cables

Heat Resistance 600V Rated PFA Insulated Wire with Silver Plated Stranded Conductor in 16 18 26 Gauge 1
