Corrosion Resistant Oil Resistant Strong Acid Resistant FEP Insulated Wire Silver Plated Copper Cable

500
MOQ
Corrosion Resistant Oil Resistant Strong Acid Resistant FEP Insulated Wire Silver Plated Copper Cable
Features Gallery Product Description Request A Quote
Features
Specifications
Conductor Material: Copper, Tinned Plated Copper Or Silver Plated Copper
Insulation Material: FEP
Conductor Type: Stranded, Stranded Or Solid
Working Temperature: -65°C ~ +200°C
Rated Voltage: AC 600V Or Lower
Color: White, Blue, Red, Black, Yellow, Green, Transparent, Yellow/Green
Number Core: Single Core Or Multiple Cores
Insulation Type: FEP, PTFE, PFA Insulated
Wire Gauge: 36AWG To 8AWG
Cross-section Area: 0.013mm2 To 8mm2
Conductor Structure: 7/0.05 To 133/0.28
Max OD: 0.65mm To 7.3mm
Rated Temperature: -65C~+200ºC
Voltage Rating: 250V, 600V
Cable Type: AF-200, AF-200-1, AFP-200, AFS-200, AFSP-200
Highlight:

Corrosion Resistant FEP Insulated Wire

,

Oil Resistant Silver Plated Copper Cable

,

Strong Acid Resistant High Temperature Wire
Basic Infomation
Place of Origin: Hunan, China
Brand Name: Sanco cable
Model Number: AF-200 Series
Payment & Shipping Terms
Product Description
Solid/Stranded Single Core Silver Plated Copper Cable Wire
Product Description

FEP Insulation Wires offer excellent corrosion resistance, oil resistance, and withstand strong acids, alkalis, and oxidants. These wires feature superior electrical insulation performance with high voltage resistance, minimal high-frequency loss, moisture resistance, and excellent insulation properties. They are highly fire-resistant, durable, and have an extended service life.

Applications include:

  • Electronic industry: Temperature compensation wire, low/high temperature heating wire, aging-resistant wire, and flame retardant wire
  • Household appliances: Internal wiring for air conditioners, microwave ovens, electronic disinfectors, rice cookers, electric heaters, ovens, frying pans, and lighting fixtures
Product Features
  • Wear and scratch resistant
  • Easy to strip
  • High and low temperature resistant (-65°C to +200°C)
  • Anti-aging and corrosion resistant
  • Electromagnetic interference resistant
Cable Specifications
Conductor Materials Tinned Plated Copper, Silver Plated Copper, Bare Copper
Conductor Type Stranded or Solid
Number Core Single Core or Multiple Cores
Insulation FEP, PTFE, PFA Insulated
Rated Voltage 600V or Below
Rated Temperature -65°C to +200°C
Color White, Blue, Red, Black, Yellow, Green, Transparent, Yellow/Green
Corrosion Resistant Oil Resistant Strong Acid Resistant FEP Insulated Wire Silver Plated Copper Cable 0
Type and Name
Type Name
AF-200 Silver Plated Copper Core FEP Insulation Install Wire
AF-200-1 Tin Plated Copper Core FEP Insulation Install Wire
AFP-200 Tin Plated or Silver Plated Copper Core FEP Insulation Shield Install Wire
AFS-200 Tin Plated or Silver Plated Copper Core FEP Insulation Stranded Install Wire
AFSP-200 Tin Plated or Silver Plated Copper Core FEP Insulation Stranded Shield Install Wire
Cable Structures
Wire gauge Cross-section area Conductor structure Max. OD of cable
36AWG 0.013mm² 7/0.05 0.65 | 0.85 | 1.1 | 1.3
32AWG 0.035mm² 7/0.08 0.75 | 0.95 | 1.2 | 1.4
30AWG 0.05mm² 7/0.10 0.85 | 1.05 | 1.35 | 1.6
28AWG 0.07mm² 7/0.12 0.9 | 1.1 | 1.4 | 1.65
- 0.1mm² 7/0.14 1 | 1.2 | 1.55 | 1.75
26AWG 0.14mm² 7/0.16 1.1 | 1.3 | 1.65 | 1.95
24AWG 0.2mm² 19/0.12 1.2 | 1.4 | 1.75 | 1.98
- 0.3mm² 7/0.23 1.25 | 1.48 | 1.8 | 2.05
22AWG 0.35/0.40mm² 19/0.16 1.4 | 1.6 | 1.95 | 2.2
20AWG 0.5mm² 19/0.18 1.6 | 1.8 | 2.2 | 2.4
- 0.6mm² 19/0.20 1.75 | 1.98 | 2.3 | 2.5
- 0.75/0.80mm² 19/0.23 1.8 | 2.1 | 2.4 | 2.6
18AWG 1mm² 19/0.26 2 | 2.2 | 2.6 | 2.9
16AWG 1.2mm² 19/0.28 2.2 | 2.4 | 2.8 | 3.1
- 1.5mm² 19/0.32 2.4 | 2.6 | 3.1 | 3.3
14AWG 2mm² 19/0.37 2.7 | 2.9 | 3.4 | 3.6
- 2.5mm² 37/0.30 3.4 | 3.6 | 4.2 | 4.4
12AWG 3mm² 37/0.32 3.6 | 3.8 | 4.4 | 4.6
- 4mm² 37/0.37 4 | 4.2 | 4.8 | 5.1
10AWG 5mm² 37/0.41 4.5 | 4.7 | 5.3 | 5.6
- 6mm² 37/0.45 4.8 | 5 | 5.7 | 5.9
8AWG 8mm² 133/0.28 6 | 6.5 | 6.8 | 7.3

Note: FEP high temperature lead wire specifications and core numbers are not limited to above regulations and can be customized.
